BLOCK PEL 230/24-1,3 AC/DC DIN Rail Power Supply (PSU), ITE, 1 Output, 34.32 W, 24 VDC, 1.3 A
PEL 230/24-1,3 is a PEL 230 series single-phase switched mode power supply. This primary switched mode power supply is concentrated on the core task of voltage and current supply. Flat step profile optimised for installation in control panels in the building automation. Safety standards are EN 61558-2-16, EN 60950-1, EN 61204-3.
- Panel installation on mounting rails, stabilised and adjustable output voltage
- Input rated voltage is 100 - 240VAC, rated frequency range from 44Hz - 66Hz /0Hz
- Output rated voltage is 24VDC, output rated current is 1.30A
- LED green power good (DC OK) signalling
- Efficiency is 82% typical
- Service-friendly spring-loaded connector system
- 3 years warranty, protection index is IP20
- UL/CSA 60950 recognised, UL 508 listed, GL approved
- Ambient temperature range from -25°C to +55°C
- Dimension is 54mm width x 89mm height x 59mm depth
Product details
| Power Supply Applications: ITE |
| No. of Outputs: 1 Output |
| Output Power Max: 34.32W |
| Output Voltage - Output 1: 24VDC |
| Output Current - Output 1: 1.3A |
| Output Voltage - Output 2: - |
| Output Current - Output 2: - |
| Output Voltage - Output 3: - |
| Output Current - Output 3: - |
| Output Voltage - Output 4: - |
| Output Current - Output 4: - |
| Input Voltage VAC: 85V AC to 264V AC |
| Power Supply Output Type: Adjustable, Fixed |
| Product Range: PEL Series |
Other details
| Brand | BLOCK |
| Part Number | PEL 230/24-1,3 |
| Quantity | Each |
| Technical Data Sheet EN |  |
