Bourns SRN5040TA-100M Power Inductor (SMD) 10 µH 2.2 A Semishielded 2.52 SRN5040TA Series 4.95mm x 3.9mm
This is a Power Inductor (SMD), 10 µH, 2.2 A, Semishielded, 2.52 A, SRN5040TA Series, 4.95mm x 4.95mm x 3.9mm product from BOURNS with the model number SRN5040TA-100M
Product details
| Inductance | 10µH |
| RMS Current (Irms) | 2.2A |
| Inductor Construction | Semishielded |
| Saturation Current (Isat) | 2.52A |
| Product Range | SRN5040TA Series |
| Power Inductor Case | 4.95mm x 4.95mm x 3.9mm |
| DC Resistance Max | 0.056ohm |
| Inductance Tolerance | ± 20% |
| RoHS Phthalates Compliant | To Be Advised |
Other details
| Brand | BOURNS |
| Part Number | SRN5040TA-100M |
| Quantity | Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |  |
| Product Change Notice EN | |
