MURATA POWER SOLUTIONS CME0305S3C Isolated Board Mount DC/DC Converter, 1 Output, 750 mW, 5 V, 150 mA

This is a Isolated Board Mount DC/DC Converter, 1 Output, 750 mW, 5 V, 150 mA product from MURATA POWER SOLUTIONS with the model number CME0305S3C

Product details

No. of Outputs	1 Output
Output Power Max	750mW
Output Voltage - Output 1	5V
Output Current - Output 1	150mA
Output Voltage - Output 2	-
Output Current - Output 2	-
Output Voltage - Output 3	-
Output Current - Output 3	-
Product Range	CME Series
Input Voltage DC Min	2.97V
Input Voltage DC Max	3.63V
DC / DC Converter Output Type	Fixed
DC / DC Converter Type	SIP
DC / DC Converter Mounting	Through Hole
Approvals & Standards	-
Width	6mm
Height	7.46mm
Depth	11.48mm

Other details

Brand	MURATA POWER SOLUTIONS
Part Number	CME0305S3C
Quantity	Each
Technical Data Sheet EN
Product Change Notice EN
