TRACOPOWER TES 1-2422 Isolated Board Mount DC/DC Converter, 2 Output, 1 W, 12 V, 40 mA, -12 V, 40 mA

This is a Isolated Board Mount DC/DC Converter, 2 Output, 1 W, 12 V, 40 mA, -12 V, 40 mA product from TRACOPOWER with the model number TES 1-2422

Product details

No. of Outputs	2 Output
Output Power Max	1W
Output Voltage - Output 1	12V
Output Current - Output 1	40mA
Output Voltage - Output 2	-12V
Output Current - Output 2	40mA
Output Voltage - Output 3	-
Output Current - Output 3	-
Product Range	-
Input Voltage DC Min	21.6V
Input Voltage DC Max	26.4V
DC / DC Converter Output Type	Fixed
DC / DC Converter Type	Surface Mount DIP
DC / DC Converter Mounting	Surface Mount Device
Approvals & Standards	-
Width	8mm
Height	7mm
Depth	16.3mm

Other details

Brand	TRACOPOWER
Part Number	TES 1-2422
Quantity	Each
Technical Data Sheet EN
Miscellaneous EN
Application Note EN
