TRACOPOWER THN 20-2412WI Isolated Board Mount DC/DC Converter, Compact, 1 Output, 20 W, 12 V, 1.67 A
This is a Isolated Board Mount DC/DC Converter, Compact, 1 Output, 20 W, 12 V, 1.67 A product from TRACOPOWER with the model number THN 20-2412WI
Product details
| No. of Outputs | 1 Output |
| Output Power Max | 20W |
| Output Voltage - Output 1 | 12V |
| Output Current - Output 1 | 1.67A |
| Output Voltage - Output 2 | - |
| Output Current - Output 2 | - |
| Output Voltage - Output 3 | - |
| Output Current - Output 3 | - |
| Product Range | THN 20WI Series |
| Input Voltage DC Min | 9V |
| Input Voltage DC Max | 36V |
| DC / DC Converter Output Type | Fixed, Adjustable |
| DC / DC Converter Type | DIP |
| DC / DC Converter Mounting | Through Hole |
| Approvals & Standards | UL |
| Width | 25.4mm |
| Height | 9.9mm |
| Depth | 25.4mm |
Other details
| Brand | TRACOPOWER |
| Part Number | THN 20-2412WI |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Miscellaneous EN | |
| Application Note EN | |
